of 6 Continuous PROFIBUS PA Instruments and Step 7ģ 2. If it is not a capacitance product, it will be under /PROFIBUS-PA/Sensors/Level/Echo/SIEMENS MILLTRONICS. NOTES: If the instrument is a capacitance product, then it will be under /PROFIBUS PA/Sensors/Level/ Capacitive/ SIEMENS MILLTRONICS. From within Hardware Config., click the Hardware Catalog icon and look for the Siemens instrument in use. Step 2a Check the Hardware Catalog for the instrument 1. Double-click the Hardware icon on the right side of the screen. Using the left side of the screen, navigate to a position similar to the screen shot below: hardware icon 2. To operate it, run SIMATIC Manager first and open a project. Box 4225 Peterborough, Ontario K9J 7B1 / Canada Tel.: (705) Fax: (705)Ģ Required Steps Step 1 Run Hardware Config Hardware Config is the segment of STEP 7 and PCS 7 used to configure the network. Siemens Milltronics Process Instruments Inc Technology Drive, P.O. However, the process is similar for all applicable Siemens SMPI Continuous Level instruments. to set up a network When and how to import a.gsd file Setting the different Siemens instruments on the bus Viewing cyclic data via STEP 7 Please note that the SITRANS LR 400 is used for illustration purposes only. This Application Guide discusses the following Running Hardware Config. Overview: SIMATIC STEP 7 is the Siemens programming software used to set up a S7-300 or S7-400 PLC. 1) While every effort was made to verify the following information, no warranty of accuracy or usability is expressed or implied.

1 Continuous PROFIBUS PA Instruments and Step 7 Configuring a Siemens Continuous Level PROFIBUS PA device in a S7-300 or S7-400 PLC Objective: Equipment: Become familiar with the steps required to configure a Siemens Continuous Level PROFIBUS PA instrument in Step 7 Siemens Continuous Level PROFIBUS MPI/PROFIBUS Interface to PLC PA instrument Terminal screwdriver.gsd file PC or Laptop SIMATIC STEP 7 ver.
